Brand: Volkswagen-commercial
Serie: Constellation Euro VI
Model: Constellation Euro VI
Engine: -
Model Year: 2024
Date of manufacture: -
Transmission: -

clamping strip for battery Brake system for Constellation Euro VI(CON6) 2024 [EUROPE]

clamping strip for battery Brake system for Constellation Euro VI(CON6) 2024 [EUROPE]
№ part number information description remark unit model
clamping strip for battery Brake system
clamping strip for battery Brake system
1 23K 607 110 B  qty: 1
Support element
23K 607 110 B  Support element 1
2 23K 607 110 D  qty: 1
Support element
23K 607 110 D  Support element 1
3 N10 158 602  qty: 1
Hexagon bolt
N10 158 602  Hexagon bolt M6X20 1
4 N01 508 39  qty: 2
Hexagon collar nut
N01 508 39  Hexagon collar nut M8 2
5 23K 607 110 C  qty: 1
Support element
23K 607 110 C  Support element 1
6 N10 156 009  qty: 2
Hex collared bolt
N10 156 009  Hex collared bolt M8X25 2
